Funk  HS17000
.

RATINGS*

Input Power (Max.): 125 hp (93W)

Input Torque (Max.): 750 lb.-ft (1017Nm)

Input no load Speed (Max.): 2900 - 4200 rpm



MOTOR ADAPTERS

SAE C & D



OIL

Capacity - 8qts. (8.8L)

Type MIL-L-2105-C or API classification GL-5



WEIGHT

Approximate dry weight:

4 speed models - 356 lbs. (161 kg)

GEAR RATIOS

(spur type gears, sliding collar shift)

Low High
5.26 1.302
2.747 1.119



SPLINES

Input - SAE 14 tooth 12/24 D.P. or SAE 13 tooth 8/16 D.P.

Output - SAE 14 tooth 8/16 D.P.





2 SPEED

I
