Funk  HMD12700
.

RATINGS*

Input Power (Max.): 140 hp (104kW)

Input Torque (Max.): 300 lb.-ft (407Nm)

Input no load Speed (Max.): 2500 rpm



MOTOR ADAPTERS

SAE C & D



OIL

Capacity - 4qts. (4.40L)

Type MIL-L-2105-C or API classification GL-5



WEIGHT

Approximate dry weight:

4 speed models - 194 lbs. (88 kg)

GEAR RATIOS

(spur type gears, sliding collar shift)

Low 2nd 3rd High
6.27:1 3.12:1 1.75:1 1:1



SPLINES

Input - SAE 14 tooth 12/24 D.P. or SAE 13 tooth 8/16 D.P.

Output - SAE 14 tooth 8/16 D.P.



4 SPEED
